TOSCANO POWER HARROW - HEAVY DUTY
ABOUT PRODUCT
Power Harrow is a tillage machine with vertical blades that turns right and left continuously.
It prepares seedbed; eliminates weed and plant residue; mixes fertilizer; creates water channels in deeper layers of the soil. It also minimizes stratification.
- Power harrow does not turnover the soil, keeps the moisture inside.
- Since the blades operates right and left, it does not hold any soil or mud.
- Vertical operation increases the water intake of the soil.
- It allows the plant roots to develop faster by preventing stratification deep in the soil.
- Specially adjusted blade alignment increases efficiency while reducing vibration.
- Seeding machine connection tool makes it possible for preparing the seedbed and sowing at the same time.
STANDARD EQUIPMENT
- Universal 3-point CAT II Linkage
- 1 3/8’’ Z6 Spline PTO Protective Shaft
- Double Outlet PTO Gearbox with 540-750-1000 RPM provides
2500-3000: min. 195 – max. 361
3500-4000: min. 236 – max. 437 Rotor Speed - 300 mm Length, 15 mm thick High Quality Blades.
- Packer Roller with Sludge Separator
- Rotor Prevention System (Developed by Toscano; prevents hose, rope, wire etc. tangling)
- Anti-Jamming System (Prevents stone jamming between rotors)
- Rear Roller Pin Adjustment
- Adjustable Levelling Profile
- Swinging Front Linkages
- Mobile & Adjustable side covers
- Removable CE Safety Guards
![Dik-Freze-Mibzer-Aparatı](https://toscano.com.tr/wp-content/uploads/Dik-Freze-Mibzer-Aparatı-300x300.jpg)
PLANTER- POWER HARROW
![toscano_dik_freze_pimli_patlatma](https://toscano.com.tr/wp-content/uploads/2021/01/toscano_dik_freze_pimli_patlatma-300x300.jpg)
PINNED PLOUGHSHARES
![IMG_20201202_110742](https://toscano.com.tr/wp-content/uploads/2020/12/IMG_20201202_110742-300x300.jpg)
SPRING PLOUGHSHARES
![on-aski-aparatı-toscano](https://toscano.com.tr/wp-content/uploads/2020/12/on-aski-aparati-toscano-300x300.jpg)
POWER HARROW FRONT CONNECTOR
![HİDROLİK MERDANE PİSTON SETi](https://toscano.com.tr/wp-content/uploads/2022/05/HIDROLIK-MERDANE-PISTON-SETi.jpg)
HYDRAULIC PISTON SYSTEM FOR ROLLER
![Quick Fit WEB](https://toscano.com.tr/wp-content/uploads/2023/12/Quick-Fit-WEB.webp)
QUICK FIT BLADES SYSTEM
![Büyük Merdane](https://toscano.com.tr/wp-content/uploads/2024/07/Buyuk-Merdane.jpg)
GRAND SIZE PACKER ROLLER Ø 536
DM Heavy-Duty Type Power Harrow | Power of Tractor | Work Width | Total Width | Blade Quantity | Weight | Cultivation Depth |
Type | kW / Hp | Cm | Cm | Quantity | Kg | Cm |
2500 | 59-103 / 80-140 | 250 | 260 | 20 | 1244 | 30 |
3000 | 66-103 / 90-140 | 300 | 310 | 24 | 1394 | 30 |
3500 | 81-118 / 110-160 | 350 | 360 | 28 | 1626 | 30 |
4000 | 88-118 / 120-160 | 400 | 410 | 32 | 1760 | 30 |
For each product, Toscano brand holds quality certificates shown below.
To claim its’ document records, do not hesitate to contact us.
![CE](https://toscano.com.tr/wp-content/uploads/CE-300x300.jpg)
![EAC-Logo](https://toscano.com.tr/wp-content/uploads/EAC-Logo-300x300.jpg)
![tselogo_tr](https://toscano.com.tr/wp-content/uploads/tselogo_tr-300x300.jpg)
![iso-9001-2015](https://toscano.com.tr/wp-content/uploads/iso-9001-2015-300x300.jpg)
TECHNICAL DETAILS
![1- dayanikli-bicak](https://toscano.com.tr/wp-content/uploads/2020/06/1-dayanikli-bicak.jpg)
DURABLE BLADES
High quality; Italian Made.
30cm length; 1,5cm thick blades.
![2- BALATA KORUMALI ŞAFT](https://toscano.com.tr/wp-content/uploads/2020/06/2-balata-korumali-_aft.jpg)
PROTECTIVE SHAFT
Shaft protects the machine and the tractor from possible damages while working with higher speeds.
![3--4-VITES;-ÇİFT-ÇIKIŞLI-ŞANZIMANWEB](https://toscano.com.tr/wp-content/uploads/3-4-VITES-ÇİFT-ÇIKIŞLI-ŞANZIMANWEB-1.jpg)
DOUBLE OUTLET PTO GEARBOX
Double outlet enables seeding machine combination. 4 rotor speeds can be adjusted with exchanging gears.
PTO Gearbox with 540-750-1000 RPM
![4- YABANCI MADDE DOLANMASINI ÖNLEYEN SİSTEM+](https://toscano.com.tr/wp-content/uploads/2020/06/4-YABANCI-MADDE-DOLANMASINI-ÖNLEYEN-SİSTEM-1-300x300.jpg)
ROTOR PREVENTION SYSTEM
An innovative system developed by Toscano, prevents the blades getting tangled by the pipe, hose, rope, wire etc.
![5- TAŞ SIKIŞMASINI ÖNLEYEN SİSTEM](https://toscano.com.tr/wp-content/uploads/2020/06/5-ta_-siki_masini-nleyen-sstem.jpg)
ANTI-JAMMING SYSTEM
Prevents stones and other stuff to get stuck between rotors.
![6-AYARLANABİLİR YAN KAPAKLAR- Dışarı toprak atmayı önleyen yan kapak çalışma yüksekliğine göre ayarlanabilir](https://toscano.com.tr/wp-content/uploads/2020/06/6-AYARLANABİLİR-YAN-KAPAKLAR-Dışarı-toprak-atmayı-önleyen-yan-kapak-çalışma-yüksekliğine-göre-ayarlanabilir.jpg)
ADJUSTABLE SIDE COVERS
Prevents the soil for pouring out of the tilling line and it is adjustable according to working height.
![7-HAREKETLİ YAN KAPAKLAR](https://toscano.com.tr/wp-content/uploads/2020/06/7-HAREKETLİ-YAN-KAPAKLAR.jpg)
MOBILE SIDE COVERS
Protects the machine from stones that could be stuck between the side covers and rotating parts by flexible spring system.
![dik freze tesviye profili](https://toscano.com.tr/wp-content/uploads/2022/04/dik-freze-tesviye-profili.jpg)
FLATTEN PROFILE
It smoothes the soil on the ground, easily adjustable.
![9- MERDANE YÜKSEKLİĞİ AYARI](https://toscano.com.tr/wp-content/uploads/2020/06/9-merdane-yksekl_-ayari.jpg)
ADJUSTABLE ROLLER LEVEL
Roller height can be adjusted by the mechanism on two sides of the machine.
![dik freze kazıyıcı](https://toscano.com.tr/wp-content/uploads/2022/04/dik-freze-kaziyici-1.jpg)
ADJUSTABLE SLUDGE SEPERATOR
Separators can be adjusted by the screw based on the needs of soil structure.
